MyPure - 96 Pro full-automatic nucleic acid extractor adopts magnetic bead separation technology, using 2.2ml deep hole plate and 96 hole magnetic rod sleeve; With different kinds of magnetic bead nucleic acid extraction kits, at most 1-192 samples can be operated at the same time. The instrument can quickly extract DNA and RNA from samples in 9~45 minutes.
(1)High throughput fast extraction. 1-96 samples can be extracted at the same time each time, or 192 samples can be processed at one time. It is especially suitable for inspection units with large sample size, third-party testing companies, hospitals, disease control, etc.
(2)Innovative plug and pull magnetic rod sleeve free disassembly mode, convenient for after-sales maintenance and replacement of magnetic rod.
The magnetic flux of the magnetic rod is above 3000GS, and the magnetic bead recovery rate is ≥ 98%
(3)Open design, suitable for all kinds of magnetic bead nucleic acid extraction reagents. Built in multiple groups of folders, which can store more than 10000 programs.
(4)10 inch color touch screen display, parameters and programs can be freely edited, and the kit can be freely matched.
(5)The instrument has 8 plate positions. The standard configuration of any plate position can be used for heating and accurate temperature control system.
(6)Rotary design, light design, net weight 35kg, small area occupied by the instrument, quiet operation.
(7)The double door design can stop at any time to confirm the intermediate process, which is convenient for reagent optimization and real-time viewing of experimental status.
(8)It is equipped with voice prompt function to prompt the installation of magnetic rod sleeve and deep hole plate to standardize user operation.
(9)It has the design of plate position recognition and positioning, and has the function of real-time automatic calibration. Even if the rotary table is out of step due to external force during operation, it can return to the target plate.
(10)With automatic pause function and pop-up reminder, it is convenient to add liquid during the extraction process
(11)Temperature control range: room temperature - 125 ℃, hole to hole difference CV value ＜ 5%, and the mixing speed is adjustable in multiple gears.
(12)The manufacturer has ISO9001 quality system certification
(13)The manufacturer shall also have the qualification for the production of nucleic acid extraction or purification reagents, and must be the proposed winner of Guangdong Alliance COVID-19 Reagent Consumables Purchase.
Basic parameters and product performance of MyPure-96Pro
Model: MyPure-96 Plus
Principle: magnetic bead method
Sample flux: 1-192
Treatment volume: 20 μ L-1000 μ L
Orifice plate type: 96 hole cone bottom deep orifice plate
Number of magnetic rods: 96
Magnetic bead recovery rate: ≥ 98%
Difference between holes: CV<5%
Heating: cracking and elution heating (room temperature to+125 "C)
Storage at room temperature: room temperature
Mixing: slow, medium, fast 1-6 programmable
Reagent type: open platform, applicable to various magnetic bead methods for extracting reagents
Extraction time: 9-45 minutes/time (determined by the project)
Operation interface: 10 inch color capacitive touch graphic display, user-friendly Chinese interface (English optional), no external computer required
Internal program: can be edited and stored freely, with unlimited number (tens of thousands)
Program management: the machine can be programmed in parallel, creating, editing, deleting, importing, exporting, etc
Expansion interface: 4 standard USB and Ethernet ports, supporting mouse, keyboard and barcode scanner
Sterilization: ultraviolet disinfection
Exhaust: fan exhaust, programmable
Data storage: It can be stored with built-in SSD
Running noise: 52dBA (typical value)
Operating temperature: 10-40C
Operating humidity: 10-90% relative humidity (non condensing)
Power supply: 100-240VAC, 45-65Hz
Boundary dimension: 750mm deep x 560mm wide x 550mm high
Weight: 35kg
The parameters of this website are for reference only. Please contact whatsapp
